Ibm System P5 Serial Connection Between Two

markslogoboss.netlify.com › ▲▲▲ Ibm System P5 Serial Connection Between Two ▲▲▲

(Redirected from IBM pSeries)

Serial Connection Cable
Ibm System P5 Serial Connection Between Two Numbers

The System p, formerly known as RS/6000, was IBM's RISC/UNIX-based server product line.

Hey All, Trying to connect to the Power5 9133-55A serial console using a serial-to-usb converter (RS232). The other end is connected via null modem. Tried minicom, putty and other Linux utilities, no The UNIX and Linux Forums. Using service applications, the HMC communicates with managed systems to detect, consolidate, and forward information to IBM service for analysis. Cabling the server and accessing Operations Console You can use Operations Console to manage a server that is running the IBM i operating system whether you have logical partitions or not. For IBM® System p5® or IBM eServer™ p5 servers in a non-HMC environment, choose from the following options:. If HTTPS traffic is restricted, ensure that the following port is open for communication: Protocol TCP port 443 with the following IP addresses: 207.25.252.200 and 129.42.160.48 If an HTTP proxy is available within your network, then the Service Agent traffic can be routed to it.

In April 2008, IBM announced a rebranding of the System p and its unification with the System i platform. The resulting product line is called IBM Power Systems.

4Models

History[edit]

RS/6000 was originally a line of workstations and servers. The server line was then renamed to the eServer pSeries in 2000 as part of its e-Server branding initiative.

In 2004, with the advent of the POWER5 processor, the family was rebranded the eServer p5.In 2005, following IBM's move to streamline its server and storage brands, worldwide, and incorporating the System brand, with the Systems Agenda, the family was renamed yet again as System p5.

The System p5 now encompasses the IBM OpenPower product line.After the introduction of POWER6 processor models, the new models were released under the System p brand, dropping the p (numbered) designation.

Processors[edit]

Whereas RS/6000 used a mix of early POWER and PowerPC processors, when pSeries came along this had evolved into RS64-III and POWER3 across the board—POWER3 for its excellent floating-point performance and RS64 for its scalability, throughput, and integer performance.

IBM developed the POWER4 processor to replace both POWER3 and the RS64 line in 2001. After that the differences between throughput and number crunching-optimized systems no longer existed. Since then System p machines evolved to use the POWER5 but also the PowerPC 970 for the low-end and blade systems.

The last System p systems used the POWER6 processor, such as the POWER6-based System p 570 and the JS22 blade. In addition IBM introduced during the SuperComputing 2007 (SC07) conference in Reno a new POWER6-based System p 575 with 32 POWER6 cores at 4.7 GHz and up to 256 GB of RAM with water cooling.

Features[edit]

All IBM System p5 and IBM eServer p5 machines support DLPAR (Dynamic Logical Partitioning) with Virtual I/O and Micro-partitioning.

System p generally uses the AIXoperating system and, more recently, 64-bit versions of the Linux operating system.

Models[edit]

BladeCenter[edit]

IBM BladeCenter JS12 (POWER6)
IBM BladeCenter JS22 (POWER6)
IBM BladeCenter JS23 (POWER6)
IBM BladeCenter JS43 (POWER6)

pSeries[edit]

IBM eServer pSeries 610 (7028-6C1 & 6E1)
IBM eServer pSeries 615 (7029-6C3, 7029-6E3) 1-2 POWER4 CPUs
IBM eServer pSeries 620 (7025-F80, 6F0 & 6F1)
IBM eServer pSeries 630 (7028-6C4, 7028-6E4) 1-4 POWER4 CPUs
IBM eServer pSeries 640 (7026-B80) 1-4 POWER3-II CPUs
IBM eServer pSeries 650 (7038-6M2) 2-8 POWER4 CPUs
IBM eServer pSeries 655 (7039-651) 4-8 POWER4 CPUs
IBM eServer pSeries 660 (7026-H80, 6H0, 6H1, M80 & 6M1)
IBM eServer pSeries 670 (7040-671) 4-16 POWER4 CPUs
IBM eServer pSeries 680 (7017 range)
IBM eServer pSeries 690 (7040-681) 8-32 POWER4 CPUs

Serial Connection Cable

The IBM p690 was, at the time of its release in late 2001, the flagship of IBM's high end Unix servers (pSeries) during the POWER4 era of processors. It was built to run IBM AIX Unix, although it is possible to run a version of Linux minus some POWER4 specific features. It was discontinued in late 2005.^[1]

It can support up to thirty-two 1.50, 1.70 or 1.90 GHz POWER4+ processors and 1 TB of RAM. It weighs well over 1000 kg. It was used in a supercomputer at Forschungszentrum Jülich in 2004.

System p[edit]

System p was rebranded Power Systems in 2008.

IBM System p 520 Express (POWER6)
IBM System p 550 Express (POWER6)
IBM System p 560 Express (POWER6)
IBM System p 570 (POWER6)
IBM System p 575 (POWER6)
IBM System p 595 (POWER6)
IBM System p5 505
IBM System p5 505Q
IBM System p5 510 (9110-510) 1-2 POWER5 CPUs
IBM System p5 510 (9110-51A) 1-2 POWER5+ CPUs
IBM System p5 510Q (9110-51A) 4 POWER5+ CPUs
IBM System p5 520 (9111-520) 1-2 POWER5 CPUs
IBM System p5 520Q
IBM System p5 550 (9113-550) 1-4 POWER5 CPUs
IBM System p5 550 Express(1.9G, 2.1G)
IBM System p5 550Q
IBM System p5 550Q Express (4-8 cores POWER5+ CPUs) (Model 9133-55A)
IBM System p5 560Q
IBM System p5 570 (9117-570) 2-16 POWER5 CPUs
IBM System p5 575 (9118-575) 8-16 POWER5 CPUs
IBM System p5 590 (9119-590) 8-32 POWER5 CPUs
IBM System p5 595 (9119-595) 16-64 POWER5 CPUs

OpenPower[edit]

OpenPower was the name of a range of servers in the System p line from IBM. They featured IBM's POWER5CPUs and run only 64-bit versions of Linux. IBM's own UNIX variant, AIX is not supported since the OpenPower servers are not licensed for this operating system.
